Optoma ZU920T WUXGA Professional Installation Laser Projector with 9800 Lumens

Ultra bright fixed lens laser projector

At 9,800 ISO lumens (8200 ANSI lumens) with 4K and HDR compatibility, the ZU920T features a dust-resistant IP5X certified optical engine for 24/7 operation capabilities, offering true maintenance-free projection for up to 30,000 hours of powerful performance in Eco mode. Other features include a motorized zoom, full motorized lens shift and built-in dual 10W speakers.

High brightness, color precision and quiet operation make this projector the ideal solution for a variety of end-user scenarios and professional environments, such as edge-blending and projection mapping, simulation, and immersive installations.

The added control flexibility of HDBaseT and LAN make this projector an affordable install and forget solution.

Features

9800 ISO lumens (8200 ANSI lumens) DuraCore laser projector

Ultra bright for immersive installations

Full motorized lens shift

Ideal for a simple set-up

Large zoom range

Motorized zoom expands placement opportunities

Long life

Delivers 30,000 hours of virtually maintenance-free operation

Control

Featuring a wide range of options you can control and monitor the projector remotely.

• RS232 Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.

• AMX compatible Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.

• Crestron RoomView Using the compatible RoomView^® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer

• Extron IPLink compatible Allows for easy installation with Extron control systems

Four corner correction

Adjust the keystone in both the vertical and horizontal plane. You can individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls or where projector placement is awkward and needs to be installed at an angle.

Portrait projection

Ideal for digital signage applications; you can rotate your projector 90 degrees to project a portrait image.

Direct power off

Power off your projector immediately or directly at the mains. This means you don’t have to wait for the projector to cool down before turning it off.

Color Management System (CMS)

Display accurate lifelike colors to best match your viewing environment. This unique feature provides you with the flexibility to fine-tune the color settings for optimal precision.

HDR compatible

Capable of receiving and displaying HDR meta data, Optoma HDR compatible projectors allow you to see far more detail and texture. Objects look more solid and life-like and the extra detail creates a greater sense of depth. It’s like looking through a window.

HDBaseT™

Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT- type cable capable up to 100 meters/328 feet without signal loss makes installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.

Full lens shift

Simplify installation with full lens shift, which provides a wider range of projector placement possibilities. This makes it easier to position the projector in your room and enables a wider range of screen size options.

Telnet

This model is able to receive comands via telenet allowing for easy installation with Telnet compatible control systems.

Constant brightness

Advanced light sensing technology allows the setting of brightness levels that will remain unchanged over time. Ideal for ensuring constant brightness for long running installations

Constant power

Allows users to set the power levels to meet individual installation requirements. Power levels can be managed to obtain the brightest picture or longest light source life - or anywhere inbetween

DuraCore

Industry leading long lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.

IP5X Dust resistant optical engine

Independently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; ideal for 24/7 maintenance free operation in challenging environments.

Wired remote

The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector; invaluable when using multiple units during live events.

Full 3D

Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.

360 projection*

Images can be projected over a 360° range* along the projector’s horizontal axis.

*For more information please refer to the user manual

True AV mute

True AV mute enables the light source of the projector to be instantly switched off and on at the press of a button. Unlike standard AV mute functionality no light is emitted from the projector, this gives 100% blackout on screen.

Integrated warping and edge blending processor

Integrated warping and edge blending processor enables multiple projectors to be warped and blended without additional dedicated hardware, reducing the cost & complexity of installation. Warping and edge blending is configured using either the projectors on screen display or with PC software depending on model.

*Compatible multi output graphics card with overlap function is required.

Specification

Display/image

Display technology

DLP

Resolution

WUXGA (1920x1200)

Brightness

9,800 lumens

ANSI brightness

8,200

Contrast ratio

3,000,000:1

Contrast ratio - full on/off

1,100:1

Native aspect ratio

16:10

Aspect ratio - compatible

4:3,16:9,16:10

Keystone correction - horizontal

30°

Keystone correction - vertical

30°

Uniformity

95%

Screen size

50" ~ 300" diagonal

Lamp info

Light source type

DuraCore Laser

LASER life

30,000 hours

Optical

Throw ratio

1.25:1 ~ 2:1

Projection distance

52.36" - 514.17"

Zoom

1.6

Zoom type

Motorised

Focal length (mm)

18.72~29.59

Lens shift

Vertical: +/-55%, Horizontal: +/-25%

Native offset

50%

Lens shift

Yes

Connectivity

Connections

LAN - wireless networking

No

General

Noise level (typical)

36dB

Noise level (max)

38dB

Security

Security bar, Kensington Lock

OSD / display languages

10 languages: English, French, German, Italian, Portuguese, Russian, Chinese (simplified), Spanish, Chinese (traditional)

24/7 operation

Yes

360° operation

Yes

Remote control

Backlit ProAV remote

Speaker count

2

Watts per speaker

10W

Networking

LAN - wireless networking

No

LAN

Yes

Power

Power supply

AC 90 – 264V 50/60 Hz

Power consumption (min)

260W

Power consumption (max)

505W

Weight and dimensions

Dimensions (W x D x H)

18.9" x 14.8" x 5.67"

Gross weight

38.58 lbs

Net weight

30.86 lbs
