STR-AN1000 7.2 Channel 8K A/V Receiver

Features

STR-AN1000

360 Spatial Sound Mapping 8K 7.2 CH A/V Receiver

Experience breathtaking 8K video and immersive 3D audio with our new 7.2-channel 8K receiver.¹ Enjoy space-filling sound from your 7.2 or 5.2.2 setup with Dolby Atmos® and DTS:X.® It’s easy to enjoy all your content with Works with SONOS, Chromecast Built-in, Apple AirPlay®, and Spotify Connect—all via Wi-Fi or Bluetooth®.^{5, 6, 7}

Discover the AN1000 features

Redefined video technology

8K & 4K/120 HDMI Connectivity

Enjoy the latest HDMI technology with support for 8K & 4K/120 video sources.^{1, 4} Equipped with two 8K HDMI inputs and two outputs the STR-AN1000 is capable of delivering the most stunning picture quality and amazing clarity.³

HDMI 2.1

While enabling higher quality video output and reduced latency from input devices like game consoles, HDMI 2.1 also provides support for Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR).^3,4

Supports Dolby Vision, HDR10, and Hybrid Log Gamma, and IMAX Enhanced

Enjoy dynamic, realistic picture quality with support for the leading HDR formats, including Dolby Vision, HDR10, Hybrid Log Gamma, and IMAX Enhanced.^{6, 8, 9}

6 HDMI Inputs/2 Outputs

The STR-AN1000 has six HDMI inputs with two inputs supporting full 8K & 4K/120 video sources, and two HDMI outputs that also support full 8K & 4K/120 video sources.^{1, 3, 4}

Awe inspiring sound for all your entertainment

Support for the most advanced object-based audio formats

With support for Dolby Atmos®, Dolby Speaker Virtualization, DTS:X®, and DTS Virtual: X the STR-AN1000 delivers an object based surround sound experience.

360 Spatial Sound Mapping

Experience true immersion. Sony’s exclusive 360 Spatial Sound Mapping technology reproduces a physical sound field that can adapt to your environment and create an experience that feels like a movie theatre or concert hall.¹³

Digital Cinema Auto Calibration IX

A new technology developed by Sony, Digital Cinema Auto Calibration IX precisely corrects the distance, angle, sound pressure, and frequency response of each speaker that’s connected to the STR-AN1000 to create the ideal sound field for any home theater setup.

Hi-Res Audio & 360 Reality Audio

Enjoy music the way the artists truly intended with High-Resolution Audio for crystal clear precision or discover a new way of listening with 360 Reality Audio for a truly immersive live concert or studio session experience.⁶ With the STR-AN1000, your music comes to life like never before.

Acoustic Center Sync

Acoustic Center Sync matches the audio to your compatible BRAVIA TV.¹²

Center Speaker Lift

Center Speaker Lift Up raises the sound from the center speaker to match what’s on the TV.

Go Wireless

Sony’s SA-RS3S & SA-RS5 wireless rear speakers and SA-SW3 & SA-SW5 wireless subwoofers (Sold sep.) are compatible with the STR-AN1000. Two subwoofers of the same model may be connected simultaneously to the receiver.

Easy Listening

Listen to all your favorite tracks, easily. The STR-AN1000 supports audio streaming via Bluetooth®, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay®.^{6, 7, 11}

Works with SONOS

After a simple setup, your Sony A/V receiver will tie in seamlessly to SONOS. From the SONOS app you will be able to turn on your A/V receiver, switch to the designated input source for playback, and control the volume of your A/V receiver.^{5, 6}

Voice Assistant Compatibility

Connect to your home’s other devices, and use voice control to operate your receiver with Google Assistant.⁸

Compatible with Sony Music Center app

Control the Receivers from your mobile device for operations like source selection, zone control, sound field control, volume control, media playback, and voice assistant setup.⁶

Roon Tested

Enjoy seamless integration with your Roon system for full access to all your music—including your digital files and streaming services—all in one place.⁶

Updated DSEE Ultimate for enhancing streaming music quality

Using AI-based technology, DSEE Ultimate accurately upscales audio to near-high-resolution sound quality, simulating a recording studio or concert environment.

Easy setup and operation

The easy-to-use graphical interface makes it super simple to start enjoying your STR-AN1000.

Zone 2 & Zone 3

Flexible multi-zone distribution capability.

Redesigned with build quality in mind

Chassis and sub-chassis

Power Supply Capacitors

New Large Capacity Power Transformer

Redeveloped digital section

With the addition of a sub-chassis structure on the rear of the front panel, the rigidity of the receiver is increased. This results in a further reduction of vibration and improved sound quality overall.

The newly designed power supply capacitors, developed by Sony, improve stability and achieve superior sound quality.

The redesigned power transformer also features a new core material and bobbin to lower distortion and improve sound quality.

The new digital section enables all signal processing to be performed on a single chip while also providing lower impedance, increased capacitance, and better stability.

New DAC enables 32-bit operations

Improved analog power for DAC

Buffer amp for DAC

Sony exclusive Pre-Amp integrated circuit

Digital PCM signal input is processed at 32-bit and converted to analog by the DAC, while DSD signal input during direct mode is natively input to the DAC and converted to an analog signal.

The DAC analog power supply uses a low- noise power supply IC to ensure that hi-fidelity performance is achieved

A new DAC analog output filter circuit was designed utilizing a JFET and op-amp improvement in noise floor. The phase rotation was shifted to a higher frequency, expanding the bandwidth and improving sound clarity for wide-bandwidth sources like high-resolution audio.

A Sony-exclusive integrated circuit was developed to improve all amplification functions of the STR-AN1000.

Fine Sound Resistor

The special resistance materials and structure, pure copper has been used in the electrodes to achieve high volumes of data with rich, vivid audio quality.

DôME FLAX PACK 5.1 home cinema system

The Dôme Flax Home Cinema speaker pack is a premium product made in France, characterized by its miniature design and "high-tech" concept. Thanks to its Flax cone, a flax-based composite sandwich membrane, this 5.1 system achieves a clear gain in definition and intelligibility for dialogues, as well as wider spatialization thanks to improved frequency response linearity. A true return to the natural sound of your films!

COMPLETE INSTALLATION The five 2-way Dôme Flax satellite loudspeakers are combined with Sub Air. Thanks to its wireless system, this subwoofer frees you from all cable constraints, delivering deep, intense sound. The package will deliver all its performance in rooms of 30 to 40 m2 for musical and cinematic emotions.
	SOUND SPOT The Dôme loudspeakers have a clean, soft design, with a totally smooth, round shape and no visible screws when the cover is fitted. Conceived as an adjustable spotlight, the Dôme is an ideal, discreet sound source for any interior.

REDISCOVER HOME CINEMA

SPECIFICATIONS Sound - Acoustics Membrane : Flax SPECIFICATION SHEET

TECHNOLOGIES

FLAX MEMBRANE Purity and precision of sound As the key component of a loudspeaker, the membrane is at the heart of our acoustic engineers' research. After more than five years of research and development, in 2013 Focal unveiled an exclusive membrane made from flax. Patented, this Flax cone is a sandwich made of very high quality French flax Fiber placed between two thin sheets of glass Fiber. It satisfies all the criteria of a high-fidelity membrane: lightness to offer good dynamics, rigidity to hold the bass and damping to deliver a neutral, natural, uncolored sound. It is an emblematic Focal innovation in many hi-fi products.

TWEETER IN AL/MG Treble finesse Membrane shape and materials are essential. For the finest treble, our engineers have patented the inverted dome tweeter, a Focal signature. The inverted dome shape offers the advantage of low directionality and a small-diameter, lightweight coil for better acceleration. As for the materials used, they combine the key points of a good loudspeaker: aluminum increases dome rigidity and reduces distortion, while the addition of magnesium provides excellent damping. The surround that connects the dome to its support uses Poron, a shape-memory material. This surround is derived from the famous Utopia Beryllium tweeter, and reduces distortion by a factor of three between 2000 Hz and 3000 Hz, where the ear is most sensitive.
