Marantz Cinema 30 Reference 11.4 Channel AV Receiver with 140W, 8K And 7 HDMI Inputs
Item #: Marantz-Cinema30
$4,800.00
Leaves Warehouse within 5-10 Business Days
Free Shipping
CINEMA 30 AV Receiver
CINEMA 30 is the most refined AV Receiver Marantz has created and redefines premium home theater sound. Engineered with proprietary technology optimized from decades of rich heritage, its 11.4 channels deliver unrivaled performance and can power even large-scale home theaters with ease.
Engineered To Perform
Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world's most demanding home theaters.
CINEMA 30
 |  |  |
 | Timeless Yet Modern StyleExcellence is heard and seen. CINEMA 30 is meticulously crafted in Japan with authentic materials in a modern style, befitting its rich heritage and stunning performance. |
No Compromise EngineeringHiFi performance technologies like HDAM SA-2, and more elevate the CINEMA 30 to performance levels seldom found in an AVR. |  |
 | Technology LeaderSeven HDMI inputs, plus digital, analog, and phono inputs – even analog video plus loudspeaker and pre-amp outputs – ensure connectivity to virtually any components you have. |
Sound Master Tuned & Calibrated For YouPowerful calibration and tuning tools are included, enabling you to get the best performance from your system. |  |
For the Soundtrack of Your Life
HEOS® Built-in has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD.
Search for Songs Across PlatformsHEOS® Built-in has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD. |
Your Whole Home in One PlaceHEOS-enabled devices allow you to control multiple rooms, all with the HEOS app. |
Search for Songs Across PlatformsUse your HEOS-enabled Marantz devices to access high-resolution music streaming and discover a whole new way to love your favorites. |
Key Technologies
TIDAL
TUNE-IN
DEEZER
CONTROL4
OVRC
HDMI EARC & ARC
Dirac Live Upgradability
SIRI
AMAZON MUSIC
BLUETOOTH
8K ULTRA HD
ROON
JOSH.AI
HI-RES AUDIO
HEOS BUILT-IN
Imax Enhanced
DOLBY Vision
DTS:X PRO
DOLBY Vision
APPLE AIRPLAY
AMAZON ALEXA
SPOTIFY
IHEART RADIO
PANDORA
CINEMA 30 AV Receiver The Most Musical Sound
CINEMA 30 is the most refined AVR Marantz has created. With premium features, optimized from decades of rich heritage, timeless style and engineered for utmost performance, Marantz CINEMA 30 is the foundation of superior home theater systems.
High Power & Low DistortionEach channel is rated at 140W with 0.05% THD, making both powerful dynamics and subtle detail a reality.
11 Channels & Countless ConfigurationsThough 11 amplifier channels are built in, CINEMA 30 can process up to 13.4 channels, making the perfect speaker layout for your room easy to achieve.
No Compromise EngineeringHi-Fi performance technologies like HDAM SA-2, monolithic symmetrical amplifiers, toroidal transformer-based power supplies, and more elevate CINEMA 30 to performance levels seldom found in an AVR.
Sound Master Tuned & Calibrated for YouPremium and custom ingredients are chosen by the Marantz Sound Masters to capture The Most Musical Sound. Powerful calibration and tuning tools are included, enabling you to get the best performance from your system.
Compatibility7 HDMI inputs, plus digital, analog, and phono inputs – even analog video plus loudspeaker and pre-amp outputs – ensure connectivity to virtually any components you have.
Timeless Yet Modern StyleExcellence is heard and seen. CINEMA 30 is meticulously crafted in Japan with authentic materials in a modern style, befitting its rich heritage and stunning performance.
A reference AV receiver, CINEMA 30 is the foundation of superior home theater systems.
Details and Specifications
Power Amplifier |
|
|---|---|
Number of Powered Channels |
11 |
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) |
- |
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) |
140 W |
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) |
175 W |
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) |
250 W |
70% Guarantee |
Yes |
Discrete Power Amplifier |
Yes |
Amplifier Topology |
Class A/B |
Current Feedback Topology |
Yes |
Bi-Amp Drive |
Assignable |
Multichannel Surround Technologies |
|
DTS |
DTS HD Master, DTS:X, DTS:X Pro, DTS Neural:X, DTS Virtual:X |
Dolby |
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround |
Other |
IMAX Enhanced, Auro 3D, Audyssey DSX, Multichannel Stereo |
Max Number of Processing (Preamp) Channels |
13.4 |
Inputs and Outputs |
|
Composite In / Out |
2 / 0 |
Component In / Out |
1 / 0 |
HDMI In / Out |
7 / 3 |
Multi-Room Video Out via HDMI |
0 / 0 |
Analog In / Fixed Level Out |
3 in / 0 out |
Phono (MM) In |
Yes |
Digital In: Optical / Coaxial |
2 / 2 |
Multi-Room Out: Analog / Digital |
2 / 0 |
Multichannel Preamp Out |
7.2 |
Subwoofer Out |
4 (independent) |
7.1 Multichannel Input |
No |
Number of Speaker Terminals |
13 |
Speaker A / B |
Assignable |
Multi-Room Speaker Terminal |
Assignable |
Front Inputs |
|
USB-A |
USB Audio |
FM Tuner with RDS |
Yes |
DAB+ Tuner |
No |
Multi-Room Video Out: Video / HDMI |
7 / 3 |
Analog In / Out |
6 / 0 |
Multichannel Pre Out |
Yes (13.4) |
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB |
No / No / No / No / Yes |
HDMI |
|
Total HDMI Inputs / No. Support 8K |
6 / 3 |
HDCP2.3 Support |
Yes |
HDMI Outputs: Main / Zone |
2 / 1 |
Analog to HDMI Video Conversion |
No |
HDMI Upscaling |
1080P/4K to 8K |
Max Resolution @ Framerate |
8K/60Hz, 4K/120Hz |
Audio Return Channel |
ARC, eARC |
Video Dynamic Range |
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
ALLM (Auto Low Latency Mode) Pass-through for Gaming |
Yes |
Variable Refresh Rate / Quick Frame Transport |
Yes / Yes |
HDMI Pass-Through in Standby Mode |
Yes |
CEC |
Yes |
DSD Audio over HDMI |
No |
Auto LipSync |
Yes |
HDMI Inputs: Back / Front |
7 / - |
Video Conversion Analog -> HDMI |
Yes |
HDMI to HDMI Scaling |
1080P/4K to 8K |
HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB |
Yes / Yes |
8K/60Hz AB / 4K/120Hz AB Pass-through In/Out |
7 / 2 (up to 40Gbps) |
HDMI 2.0: 3D / 4K / CEC / ARC |
Yes / Yes / Yes / Yes |
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
Yes / Yes / Yes / Yes / Yes |
Variable Refresh Rate / Quick Frame Transport / Quick Media Switching |
Yes / Yes / No |
8K Signal Pass-through / Scaling / GUI Overlay |
Yes / Yes / Yes |
4K Signal Pass-Through / Scaling / GUI Overlay |
Yes / Yes / Yes |
DSD Audio Capability |
Yes |
Performance Technologies |
|
Copper Plated Chassis |
Yes |
Toroidal Power Supply Transformer |
Yes |
Hyper Dynamic Amplifier Modules (HDAM) (List version) |
Yes |
Pure Direct Mode |
Yes |
Gold Plated RCA Terminals |
Yes |
Clock Jitter Reducer |
Yes |
Acoustic Room Correction |
|
Audyssey |
MultEQ XT32 / Dirac Live (upgrade) |
Audyssey Dynamic EQ / Dynamic Volume |
Yes / Yes |
Audyssey LFC |
Yes |
Dirac Live Support |
Yes |
Variable Cross Over |
Yes |
Optimized Bass Redirection |
Yes |
Bass Sync |
Yes |
Dirac Live Upgradability |
Yes |
Music File Support |
|
Lossy Formats |
MP3 / WMA / AAC |
Lossless Formats |
FLAC HD 192/24 / WAV 192/24 / ALAC 192/31 |
DSD Audio |
2.8 MHz / 5.6 MHz |
Gapless Playback |
FLAC, WAV, ALAC, DSD |
Compressed Audio Enhancer: MDAX2 |
Yes |
Network Audio Sharing |
Yes |
Streaming Services |
|
HEOS Multi-room and Streaming |
Yes |
AirPlay Audio Streaming |
AirPlay2 |
Internet Radio |
TuneIn |
Spotify* |
Spotify Connect |
Pandora |
No |
SiriusXM |
Yes |
Other Streaming Services * |
Amazon Music HD / Amazon Music / TIDAL / Deezer / Napster / SoundCloud / Mood Mix |
Roon Tested |
Yes |
Network Connectivity |
|
Ethernet Ports |
Yes |
Wi-Fi (include version / band) |
Yes |
Bluetooth (Include version) |
Yes |
Bluetooth Re-transmit for Bluetooth Headphones |
Yes |
Smart Home Integration and Control |
|
Voice Assistant Compatibility |
Alexa / Google Voice Assistant / Apple HomePod |
App for Smart Phones & Tablets (iOS & Android) |
Marantz AVR App |
HEOS Multi-Room Integrated |
Yes |
HEOS Link Compatibility: IR/ IP |
Yes / Yes |
Multi-Room Zones |
2 |
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog |
2 Ch / 2 Ch / Yes / Yes |
Zone Audio Output: Speaker / Preout |
Yes / Yes |
Zone HDMI Output from HDMI Source |
Yes |
Control Connectivity |
|
IP Control / RS232 Control / Web Control / App Control |
Yes |
IR Flasher In |
Yes |
Marantz Remote Bus |
Yes |
DC Trigger Output |
3 |
HDMI Diagnostics |
Yes |
Others |
|
Front Display |
2 line FLD + port hole OLED |
GUI Languages |
3 |
Setup Assistant |
Yes |
Smart Select on Remote |
Yes |
Firmware Update by Network / USB |
Yes / Yes |
ECO Mode |
Yes |
Auto Power off |
Yes |
Sleep Timer |
Yes |
GUI Overlay on HDMI |
Yes |
CEC |
Yes |
Auto Speaker Setup by Microphone |
Audyssey MultEQ XT32 / Dirac Live (upgrade) |
Graphic User Interface - GUI |
Modern HD GUI |
Smart Select |
Yes |
General |
|
Available Colors |
Black / Silver-Gold |
Metal Front Panel |
Yes |
System Remote Control |
RC-051SR |
Power Consumption in W |
780 |
Power Consumption No-Sound (ECO on/off) in W |
65 W / 110 W |
Standby Consumption in W |
0.2 |
CEC Standby Consumption in W |
0.5 |
Network Standby Consumption in W |
Less than 2.0 |
Pre-Programmed / Learnable / LCD Display |
Yes / Yes / Yes |
Weight in lbs. |
42.8 |
Maximum Dimensions (Inches) |
Antenna: Horizontal: (W x D x H): 17.4 x 18.0 x 7.5 Antenna: Vertical: (W x D x H): 17.4 x 18.0 x 10.2 W/o Antenna: (W x D x H): 17.4 x 17.6 x 7.5 |
What's in the Box |
|
| Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antennas, AC cord | |
Downloads
Specs
Item #: Marantz-Cinema30
Manufacturer Part #: Cinema30
